PDM32

MoTeC’s 32 output Power Distribution Module (PDM32) is designed to provide electronically switched power to the various electrical systems in the vehicle such as motors, lights and solenoids, and electronic devices such as ECUs and data acquisition systems.

The module replaces conventional relays, fuses and circuit breakers, simplifying wiring and reducing weight while increasing reliability.

An IP68 rated PDM32M can be ordered for applications exposed to extreme environmental conditions.

NEWS: MoTeC CAN Keypads are now available for use with MoTeC PDMs.

Basic Specifications

Outputs

• 8 x 20 A outputs - 20 A continuous, 115 A transient (typical)
• 24 x 8 A outputs - 8 A continuous, 60 A transient (typical)

Inputs

• 23 x Switch inputs

Communications

• 1 x CAN

Diagnostic Information

• Output current and voltages
• Input voltages
• Error status

Physical

• Connectors

- 1 x 37 pin Autosport connector

- 1 x 26 pin Autosport connector

- 1 x 1 pin Autosport connector

- 1 x 8 pin Autosport connector

• Case size 180 x 60 x 28 mm

Weight 405 grams

Download Datasheet

• CDS14100 PDM32 Power Distribution Module
• CDS14100M PDM32 Power Distribution Module (Marine)
